Quad & Lawnmower Folding Ramps
Our most popular ramps are available to purchase through our online shop. If you don’t find what you are looking for or have specific requirements please contact us with details of the application, Height that the ramps will need to go up to, The Weight of the machine or implement, and the type of connection you require.
Below is a table showing the different specifications of our standard ramps.
| CODE FOLDABLE | LOADING CAPACITY PAIR IN KG / WHEELBASE 500 mm |
LOADING CAPACITY PAIR IN KG / WHEELBASE 750 mm |
LOADING CAPACITY PAIR IN KG / WHEELBASE 1000 mm |
LENGTH (mm) | WIDTH (mm) | WEIGHT Pair (kg) |
|---|---|---|---|---|---|---|
| H30/15SP | 480 | 480 | 480 | 1500 | 200 | 12 |
| H30/20SP | 380 | 380 | 380 | 2000 | 200 | 15 |
| H30/25SP | 300 | 300 | 300 | 2500 | 200 | 18 |
| H30/30SP | 250 | 250 | 250 | 3000 | 200 | 22 |
| H30/35SP | 180 | 180 | 180 | 3500 | 200 | 26 |
£enquire
excluding VAT
